iMAG 4700 Series In-line Magnetic Flow Meter
Call for pricing
Brand: Seametrics
Applications: Water and Wastewater, Municipal, Pump Skids, Pump Stations, Package Plants, Filtration Systems, Reclaimed Water, Hydraulic Fracturing (Fracking).
Now Available for 2″ to 12″ line sizes
Certified to NSF/ANSI standard 61
IP68 rated
Optional datalogger
External AC or DC power versions, with battery backup
Minimal straight pipe
Meter mounted rate/total indicator
Pulse and 4-20mA output standard
Call for pricing
Brand: Seametrics
Applications: Water and Wastewater, Municipal, Pump Skids, Pump Stations, Package Plants, Filtration Systems, Reclaimed Water, Hydraulic Fracturing (Fracking).
Now Available for 2″ to 12″ line sizes
Certified to NSF/ANSI standard 61
IP68 rated
Optional datalogger
External AC or DC power versions, with battery backup
Minimal straight pipe
Meter mounted rate/total indicator
Pulse and 4-20mA output standard
Call for pricing
Brand: Seametrics
Applications: Water and Wastewater, Municipal, Pump Skids, Pump Stations, Package Plants, Filtration Systems, Reclaimed Water, Hydraulic Fracturing (Fracking).
Now Available for 2″ to 12″ line sizes
Certified to NSF/ANSI standard 61
IP68 rated
Optional datalogger
External AC or DC power versions, with battery backup
Minimal straight pipe
Meter mounted rate/total indicator
Pulse and 4-20mA output standard
Description
The iMAG-Series are the most economical flanged electromagnetic flowmeters on the market. With electrodes designed to discourage fouling, it is available in 2” to 12” pipe in municipal or industrial water, waste and reclaimed water, pump stations, and packaged plant applications. Minimal straight pipe requirements allow iMAG-Series meters to be used in piping configurations where there is little space between the meter and an elbow. iMAG-Series meters are CE certified, certified to NSF/ANSI standard 61 and are rated IP68 for applications where the meter may be operated under water to a depth of at least 10 feet (3 meters) continuously. Both rate and total indication are standard. Rate and total units and pulse scaling can be set via the front panel touch key pad by the user. Bidirectional flow reading is standard with totals available in forward, reverse, net flow, batch forward flow, and batch reverse flow. Built-in data logging is available as an option for secure flow logging. A power/output cable allows outputs for use with a variety of Seametrics and other displays and controls for remote reading and telemetry applications. Pulse output and 4-20mA passive current loop are standard on all units. Additionally, high speed digital, and Modbus® protocol outputs are optional. The iMAG 4700p can be supplied with an optional internal AC power supply
iMAG4700p
Premium Flanged In-line Magmeter, Includes One Pulse and 4-20mA Output
iMAG 4700 Municipal/Industrial Magmeter
Battery Powered Flanged In-line Magmeter, Includes One Pulse Output
iMAG4700r
Remote Display Flanged In-line Magmeter, Includes One Pulse Output
PC42 Single or Dual Regulated Power Supply
The PC42 dual regulated power supply is designed for applications in which a magmeter is used together with a 4-20 mA transmitter such as the AO55 or FT440. Although a single 24 Vdc power supply can be used, there is a risk of a ground loop interfering with proper operation of the 4-20 mA current loop. This risk is eliminated by the dual power supply.
Related Products
RANGER Node
